Model | Device Capacity |
Device Layout |
Device Slot (in mm) |
Cabinet Dimension (in mm) |
Weight |
CM13-10AC | 10 | 1 Deck x 10 Ports |
D350*W46*H270 | D580*W704*H396 |
|
CM13-20AC | 20 | 2 Decks x 10 Ports |
D350*W46*H270 |
D580*W725*H749 with 4" Dual Medical Silent Wheels (135mm) & Top Handle (60mm) |
47 KG |
CM13-30AC | 30 | 3 Decks x 10 Ports |
D350*W46*H270 | D580*W725*H1157 with 5" Rubber Wheels (160mm) |
71 KG |
CM13-40AC | 40 | 4 Decks x 10 Ports |
D350*W46*H270 |
D580*W725*H1430 with 5" Rubber Wheels (160mm) |
95 KG |
SPECIFICATION AND FEATURES
- Supports Charging: Laptops, Chromebooks, Notebooks, Ultrabooks, Macbooks, Tablet PCs, iPads, Samsung Tablets & many more.
- Multi-Function Charging Control System, to prevent circui trip and overcharging of devices (which cause bloating of battery)
- Earth Leakage Circuit Breaker (ELCB) / Over Current Protection to safeguard devices
- Automatic Cooling Fan: to cool down the devices while charging, the hot air are ventilated through the hole panels
- Power Adapters Management are located at Back Door, keeping power adapters and power cords compact, neat and organised
- UV Disinfection Lamp
- Blue-Tinted Acrylic Window for UV Eye Protection.
- Heavy-Duty Castor Wheels (1 Set of 4 with Brakes)
- 1 Push Handle
- Small in Size, Big in Capacity.
- Separator Material: ABS Anti-Flaming, Environmental, provides cushion and prevents scratches on devices
- Cabinet Body Material: 1.2mm Cold Roll Steel (with Powder Coating) for Higher Durability & Security
- Cabinet Color: Black
- Input: 220-240V
- Certificates: CE
- Widely Use In: School, Classroom, Office, Hotel, Hospital, Airport, Gym & etc.
- Accessories:
- Power Cable (x1)
- Security Keys
- User Manual Multi-Funtion Power Management System (for V-Lab CM13 AC Charging Laptop Cart)
*All pictures above are for illustration purpose only.
