SPECIFICATIONS & FEATURES

• Ergonomic View for Touch Screen Access, suitable for standing heights around 150-185cm (just an approximate)
• 8 inch Multi-Function Touch Screen (with a resolution of 1024x768 HD Display):
  1. Display Charging Status of devices
  2. Synchronization status
  3. Unlock Digital Lock Interface
     • Access Card (Compatible with MIFARE and ID Card)
     • Face Recognition (Camera: ≥ 720P pixels)
     • 6-Digit Passcode (Input via Touch Screen)
  4. Set Automatic Charging Time to prevent device overcharging (which causes battery bloating) and UV sanitization to kill germs and bacteria, ensuring devices stay clean and safe for users.
  5. History Log / Traceability Management
     • Records a list of users who took out and returned the devices on certain date and time
     • Records a list of dates and times the disinfection was activated
• Single Port Output: 25W (Max) = 5V 3A / 9V 3A / 12V 2.08A / 15V 1.67A / 20V 1.25A
• Data Synchronization:
  • Protocol standard: USB 2.0 (electrical specifications comply with USB-IF certification), supporting both charging and data synchronization functions;
  • Data transmission rate: Up to 480Mbps.
  • Synchronization trigger: Automatically enters synchronization status when connected to an external USB, or triggered by touch screen commands.
• Electrical Safety Protection：
  • Overvoltage protection: When the output voltage exceeds 5.5V, the power supply of that port will be automatically cut off (automatically resumes when the overvoltage is removed).
  • Short circuit protection: When a short circuit is detected at the interface (impedance ≤0.5Ω), the corresponding circuit will be immediately cut off (automatically resumes when the short circuit is removed).
  • Overload Protection: When the current of a single port exceeds 2.5A, the power supply of that port will be automatically cut off (automatically resumes when the overload is removed).
• Input: 90V-120V / 200V-240V 50/60Hz
• Rated Power: 1200W
• Supports: Android, iOS
• Separator Material: ABS Anti-Flaming, Environmental, provides cushion and prevents scratches on devices
• Body Material: Galvanized Door with Clear Window to view devices and charging status.
• Cabinet Body Material: 1.0mm Cold Roll Steel Plate (with Powder Spray Coating) for Scratch-Resistant and Wear-Resistant
• CNC Number Labels on Device Slot, to organise devices neatly with assigned running number
• USB-C Ports are located at Back Door for easy cable managment, use 1 meter charging cable.
• Power Cord Cable Management located at the side of the cart
• Intelligent Recognition LED Indicator near front door: Red: Charging; Green: Fully Charged / Standby; Blue: Syncing
• Active Heat Dissipation
  • Built-in 12V DC silent brushless fan (air volume ≥30CFM, power ≤5W), which starts and stops with the system switch.
  • Heat dissipation holes are opened on both sides and the door panel of the cabinet, forming air convection with the fan to ensure the stable operation of electrical components, such as the power module and USB control board.
• Heavy Duty Wheels: Mute 360 Degree Movable Wheels with Brakes for ease mobility
• Push Handle, 2 Pcs on each sides
• Emergency Access: In the event when there is no power supply to open cart's front door, administator can unlock back door with key to open front door.
• Certificates: CE, RoHS, COC
• Widely Use In: School, Classroom, Office, Hotel, Hospital, Airport, Gym & etc.
• Accessories:
  1. Power Cable
  2. Security Keys

*All pictures above are for illustration purpose only.
